TOT SERIES

Torus TOT AVR – Tone Audio Product of the the year ProductofTheYearAccessory

Technology

TOT AVR ELITE Series

TOT MINI and TOT Max

  • Toroidal Isolation

  • Noise Filtering

TOT AVR

  • Toroidal Isolation

  • Noise Filtering

  • Automatic Voltage Regulation

  • Smart Ethernet

Description

Torus Power’s “TOT” Series consists of compact models that bring toroidal power conditioning to a new price point, affordable for most applications and packed with features, the TOT Series is an easy choice to improve performance of all audio and video systems.

The TOT AVR ELITE, rated as 4 amps, is a full-feature state-of-the-art power transformer, isolating and protecting your system. Like all products, the AVR ELITE series provides true isolation (using massive toroidal transformers) and protects all connected equipment from the risk of severe power line surges using series-mode surge suppression. It’s advanced Automatic Voltage Regulation keeps voltage to the connected equipment within + 8V of the nominal voltage (220-240 VAC). Use with Torus Power Connect to enable remote power management via a web browser on a computer, smart phone or tablet.

The TOT MINI, rated at 3 amps, is ideal to provide clean power to Audio/Video systems, projectors, flat panels, powered speakers, media/ source players, processors, or network devices.

The TOT MAX, rated at 8 Amps, can provide current to demanding power hungry systems including substantial power amplifiers.

The TOT AVR, rated at 4 amps, provides automatic voltage regulation to your connected equipment (220-240 VAC + 10V with a mains voltage of 170-270 VAC), thereby enhancing protection against voltage sags, brownouts and surges; plus Smart Ethernet connectivity and RS232 interface. Ideal for home theater receivers and 2-channel audio systems.

All TOT models feature a courtesy USB charger outlet. Options include a dress aluminum faceplate (Black or Silver) and a 19″ rack mount adapter kit. TOT units include circuit protection through a replaceable varistor. Torus Power non-sacrificial Series Mode Surge Suppression (SMSS) is also available as a factory-installed option.

Torus Power TOT CE Icons

TOT CE AVR

SPECIFICATIONS

MODEL

TOT MINI CE TOT MAX CE
CONFIGURATION SH (Shelf Model), RK (Rack Mount), IW (In-Wall)
CHASSIS 2U
INPUT VOLTAGE 220 – 240 VAC
OUTPUT VOLTAGE 220 – 240 VAC
INPUT BREAKER 1 X 3A FUSE 1 X 8 FUSE
OUTPUT CURRENT 3 A 8 A
POWER RATING 680 VA 1,820 VA
FREQUENCY 50 – 60 Hz
NO. OUTLETS 3 4
INLET TYPE IEC 15A (Shelf, RK)
OUTLET TYPE SCHUKO CEE 7/7, 16A / 250V
OUTPUT USB 5.1 VDC nominal / 2300 mA maximum
WEIGHT (SHELF) 25.5 LBS (11.64 KG) 38.9 LBS (17.7 KG)
WEIGHT (RM) 26.2 LBS (11.89 KG) 39.8 LBS (18.1 KG)
WEIGHT (IW) 29.5 LBS (13.4 KG) 43.3 LBS (19.7)
DIMENSIONS (SH) W X H X D – MM 318 X 101 X 268 318 X 101 X 369
DIMENSIONS (SH) W X H X D  – IN 12.5 X 4.0 X 10.5 12.5 X 4.0 X 14.5
DIMENSIONS  (RK) W X H X D – MM 480 X 88 X 271 480 X 88 X 373
DIMENSIONS  (RK) W X H X D – IN 18.9 X 3.4 X 10.7 18.9 X 3.4 X 14.7
DIMENSIONS (IW) W X H X D – MM 419 X 90 X 381 419 X 90 X 483
DIMENSIONS (IW) W X H X D – IN 16.5 X 3.5 X 15.0 16.5 X 3.5 X 19.0
MODEL TOT AVR CE
FACEPLATE 12” BLACK
POWER VA 920
INPUT 220 – 240 VAC Range from 170 – 270 VAC
OUTPUT 220 – 240 VAC ± 10V
INPUT FUSE 1 X 4A
INLET  IEC 320-C14
OUTPUT CURRENT 4A
FREQUENCY 47-63 Hz
NO. OUTLETS 3
WEIGHT LB  34.3
WEIGHT KG  15.6
SIZE MM W X D X H 318 X 369 X 89
SIZE IN W X D X H 12.5 X 14.0 X 3.5
MODEL TOT AVR ELITE 4 CE TOT AVR ELITE 4 CE TVSS
FACEPLATE 19 ” RACK MOUNT (RK), 17″ SILVER (CS), 17″ BLACK (CB)
POWER VA 920
INPUT 170 – 270 VAC
OUTPUT 230 VAC
INPUT FUSE 1 X 4A
INLET  SCHUKO 7/77
OUTPUT CURRENT 4A
SURGE SUPPRESSION SMSS SMSS & TVSS
FREQUENCY 50 Hz
NO. OUTLETS 4
WEIGHT LB  35.3 35.7
WEIGHT KG  16 16.2
SIZE CM W X D X H 43.2 X 48.3 X 10.2
SIZE IN W X D X H 17 X 19 X 4
